An Overview of the ccwr Package for R

Introduction

ccwr implements the clone-censor-weight (CCW) procedure for emulating a target trial from observational time-to-event data.

Suppose we want to know whether surgery improves survival in lung cancer patients. Naively comparing those who had surgery against those who did not can be badly misleading. A central culprit is immortal time bias: to be counted in the “surgery” group, a patient must first survive long enough to receive surgery, and that guaranteed survival time is then credited to the surgery group as though it were a benefit of the operation.

CCW is the standard target-trial-emulation remedy for this bias, and its name traces the three steps it takes:

Clone – each patient is duplicated into every treatment strategy being compared, so that at the start of follow-up every clone is compatible with the strategy it is assigned to.
Censor – a clone is censored the moment the patient’s observed history stops being consistent with the strategy that clone represents.
Weight – inverse-probability-of-censoring weights undo the selection bias introduced by that artificial censoring.

The package exposes these steps as a small set of composable functions: they clone a subject-level dataset across strategies, apply the artificial censoring each strategy implies, expand the result into the person-time format that an inverse-probability-of-censoring weighted (IPCW) analysis requires, and fit the weighted per-protocol effect.

The rest of this document is organised as follows. Section 2 reviews target trial emulation and introduces the data. Section 3 works through the method on that data, presenting each of the three ideas – cloning, artificial censoring, and IPC weighting – with its rationale and immediately in code, building up the analysis dataset step by step and then estimating the weighted per-protocol effect. Section 4 summarises the workflow.

We assume familiarity with the basic ideas of target trial emulation and inverse-probability weighting. The target-trial framework we emulate is set out by Hernán and Robins [2016] and Hernán, Wang and Leaf [2022]; marginal structural models and the use of IPC weighting to adjust for time-varying selection are developed by Robins, Hernán and Brumback [2000] and applied by Hernán, Brumback and Robins [2000], with inverse-probability-of-censoring weighting itself introduced by Robins and Finkelstein [2000]. Hernán [2018] sets out the cloning-censoring-weighting strategy for treatment-duration questions of the kind considered here. Maringe et al. [2020] discuss trial emulation specifically as a remedy for immortal-time bias, and Gaber et al. [2024] give a practical account of implementing clone-censor-weight with stabilized IPCW, which the implementation here follows.

Target trial emulation

The problem it solves

A randomized controlled trial (RCT) can directly compare “following strategy A to the end” versus “following strategy B to the end.” The difficulty with observational data is that no such assignment exists. People are not split into A/B at baseline; over time they begin, switch, or stop treatments according to their evolving health.

The hardest case is when the strategy is defined by something that happens in the future, not at baseline. Consider the strategy “receive surgery within 6 months of diagnosis.” At diagnosis (baseline) we cannot know whether a person will go on to have surgery within 6 months. If we split people at baseline into “surgery” versus “no surgery,” anyone who dies before surgery is automatically classified into the no-surgery arm, producing immortal time bias.

Hernán and Robins [2016] proposed a simple remedy: specify the RCT you would ideally run (the target trial), then emulate that trial using observational data. A target trial is specified through seven components. Table 1 maps those components onto this vignette’s running example (surgery within 6 months of diagnosis).

Target trial components mapped onto the running example.
Target trial component	Definition in this example
1. Eligibility	Patients alive at diagnosis and not yet operated on
2. Treatment strategies	(A) surgery within 6 months / (B) no surgery within 6 months
3. Assignment	No assignment in observational data $\rightarrow$ replaced by cloning
4. Follow-up	From baseline (diagnosis) to death or end of observation
5. Outcome	Overall survival
6. Causal contrast	Per-protocol effect (effect of following the strategy to the end)
7. Analysis	Artificial censoring + IPCW, then weighted survival analysis

Data

The ccwr package is concerned with the causal analysis of time-to-event outcomes. The bundled lungcancer dataset contains 200 simulated lung cancer patients followed for up to one year after diagnosis; 106 received surgery within six months and 48 died during follow-up.

data(lungcancer)
head(lungcancer)
#>      id surgery timetosurgery death sex charlson perf stage emergency fup_obs
#> 1 P5958       0            NA     0   2        1    2     2         1  365.24
#> 2 P3075       0            NA     0   2        1    0     2         0  365.24
#> 3 P1410       0            NA     0   1        1    2     1         0  365.24
#> 4 P4957       0            NA     0   2        0    1     1         0  365.24
#> 5 P7340       0            NA     1   1        0    2     2         1  123.00
#> 6 P1917       0            NA     0   2        0    0     1         0  365.24
#>        age deprivation
#> 1 79.57290        0.42
#> 2 82.91855        0.07
#> 3 84.03011        0.22
#> 4 78.34634        0.12
#> 5 83.63860        0.40
#> 6 82.26147        0.03

The columns the analysis relies on are:

id: patient identifier
surgery: whether the patient received surgery (1) or not (0)
timetosurgery: time from baseline to surgery (NA if never operated on)
death: whether the patient died (1) or not (0) – the outcome event
fup_obs: observed follow-up time

The remaining columns (sex, charlson, perf, stage, emergency, age, deprivation) describe patient characteristics that can be used as covariates when estimating censoring weights. Below we use age and sex.

Reading your own data

The example uses the bundled lungcancer data, but the same workflow runs on any subject-level dataset that provides, at a minimum:

an identifier column for each patient;
a binary treatment column, coded 0 / 1;
a time-to-treatment column (numeric, NA for the untreated);
a binary outcome column, coded 0 / 1;
a numeric follow-up-time column.

The column names are up to you: you pass them to the relevant function arguments (the treatment, outcome and follow-up names to the policy and censoring helpers; the identifier to create_final_data(); any covariates to estimate_censoring()), as we do in Section 3. Any additional columns are carried along and can serve as covariates.

read_trial_data() is a small convenience wrapper for reading such data from a CSV file into a tibble. It imposes no particular column structure; it simply reads the file:

my_data <- read_trial_data("path/to/your-data.csv")

Clone-censor-weighting

We now walk through the method on the lungcancer data. Each of the three ideas that give the method its name – clone, censor, weight – is presented with its rationale and then applied immediately in code, checking the result at each turn. A final step estimates the effect from the clone-censor-weighted data. We compare two strategies with a six-month grace period ( $\approx 182.62$ days).

The grace period is central to this analysis: it is the window during which a patient is still considered compatible with the “surgery” strategy. A patient who has surgery within the grace period is consistent with the treated strategy; one who does not is consistent with the control strategy. Hernán [2018] discusses how such duration strategies should be specified and emulated.

arms         <- c("Control", "Surgery")
grace_period <- 182.62

Clone

Each eligible individual is duplicated once per strategy being compared. With two strategies, one person becomes two clones. At baseline nobody has yet violated any strategy, so at the moment of duplication both clones share an identical history. This makes the baseline covariates exactly balanced across arms, removing the source of immortal time bias.

clone_arms() carries this out, returning a list with one data frame per arm. At this point the two are identical copies of the original data; the strategy-specific logic comes next.

clones <- clone_arms(lungcancer, arms)
names(clones)
#> [1] "Control" "Surgery"
sapply(clones, nrow)
#> Control Surgery
#>     200     200

Censor

Each clone is artificially censored the first moment it deviates from the strategy it represents.

The “surgery within 6 months” clone: if 6 months pass without surgery, the clone has now violated its strategy and is censored at the 6-month mark. If surgery occurs in time, the clone remains in the risk set.
The “no surgery within 6 months” clone: if surgery occurs within 6 months, the clone is censored at the time of surgery.

In other words, each clone stays under follow-up only while it remains consistent with its strategy.

The intuition, traced by hand

Before applying the package functions, it helps to trace the censoring by hand on a small dataset. The bundled patients13 dataset is exactly that: the 13 patient records of Figure 2 in Maringe et al. [2020], chosen to cover every censoring pattern that can arise in registry data. Times are in days, on the same scale as lungcancer.

data(patients13)
patients13
#>    id surgery time_to_surgery death followup
#> 1   A       1              61     1      300
#> 2   B       1             150     0      365
#> 3   C       1              20     1      150
#> 4   D       1             140     0      160
#> 5   E       1              10     0      300
#> 6   F       1             220     1      320
#> 7   G       1             340     0      365
#> 8   H       1             200     0      300
#> 9   I       0              NA     0      365
#> 10  J       0              NA     1      260
#> 11  K       0              NA     1       40
#> 12  L       0              NA     0      140
#> 13  M       0              NA     0      320

Here time_to_surgery is the time to surgery (NA if the patient never had surgery), followup is the observed follow-up time, and death is the event indicator ( $1$ = death).

Using the same six-month grace_period as above, we work out when each clone is censored. The one subtlety is that a clone can only deviate from a strategy if it is still under observation at the moment the deviation would occur: a patient whose follow-up ends before the grace period closes never gets the chance to violate the “surgery within 6 months” strategy, so their observed outcome still counts.

## --- Surgery-arm clone: surgery must occur within the grace period ---
##   * surgery in time                -> adherent, follow to end of observation
##   * still unoperated when the
##     grace period closes            -> censored there
##   * follow-up ends before that     -> no deviation, observed outcome stands
surg_clone <- within(patients13, {
  adherent <- !is.na(time_to_surgery) & time_to_surgery <= grace_period
  deviates <- !adherent & followup > grace_period
  fu_time  <- ifelse(deviates, grace_period, followup)
  status   <- ifelse(deviates, 0, death)   # censored -> status = 0
  arm      <- "Surgery"
})

## --- Control-arm clone: surgery must NOT occur within the grace period ---
##   * surgery within the grace period -> censored at the time of surgery
##   * otherwise                       -> adherent, follow to end of observation
ctrl_clone <- within(patients13, {
  deviates <- !is.na(time_to_surgery) & time_to_surgery <= grace_period
  fu_time  <- ifelse(deviates, time_to_surgery, followup)
  status   <- ifelse(deviates, 0, death)
  arm      <- "Control"
})

cols <- c("id", "arm", "fu_time", "status")
rbind(surg_clone[cols], ctrl_clone[cols])
#>    id     arm fu_time status
#> 1   A Surgery  300.00      1
#> 2   B Surgery  365.00      0
#> 3   C Surgery  150.00      1
#> 4   D Surgery  160.00      0
#> 5   E Surgery  300.00      0
#> 6   F Surgery  182.62      0
#> 7   G Surgery  182.62      0
#> 8   H Surgery  182.62      0
#> 9   I Surgery  182.62      0
#> 10  J Surgery  182.62      0
#> 11  K Surgery   40.00      1
#> 12  L Surgery  140.00      0
#> 13  M Surgery  182.62      0
#> 14  A Control   61.00      0
#> 15  B Control  150.00      0
#> 16  C Control   20.00      0
#> 17  D Control  140.00      0
#> 18  E Control   10.00      0
#> 19  F Control  320.00      1
#> 20  G Control  365.00      0
#> 21  H Control  300.00      0
#> 22  I Control  365.00      0
#> 23  J Control  260.00      1
#> 24  K Control   40.00      1
#> 25  L Control  140.00      0
#> 26  M Control  320.00      0

Three rows carry the whole idea. Patient A has surgery on day 61: adherent in the surgery arm and followed to death on day 300, but censored on day 61 in the control arm. Patient F is the mirror image – surgery on day 220, after the grace period has closed – so the surgery-arm clone is censored at day 182.62 while the control-arm clone remains adherent and contributes its death on day 320. Patient K never has surgery and dies on day 40, before the grace period closes: neither strategy has been violated, so that death counts in both arms. This table is the core intuition of CCW.

Deriving the grace-period rules

The package derives exactly this censoring from the grace-period rules, on the real data. Two helper functions describe how each arm’s emulated outcome, follow-up, and censoring should be derived. Note that they do not touch the data yet: they return the rules (as expressions), one nested list entry per arm, which are evaluated in the next step.

create_policy_A() produces the rules for the emulated outcome and follow-up under the grace-period policy, and create_censoring_logics_A() produces the rules for the censoring indicator and the time at which that indicator can first be determined. Here we name the resulting columns explicitly (outcome, fup, censoring, fup_uncensored); if these arguments are omitted, the dot-prefixed names .outcome, .fup, .censoring and .fup_uncensored are used instead.

apply_logics() evaluates a set of rules against each arm’s data, so we call it once per rule set.

policies <- create_policy_A(
  arms,
  treatment         = "surgery",
  time_to_treatment = "timetosurgery",
  grace_period      = grace_period,
  outcome           = "death",
  followup          = "fup_obs",
  clone_outcome     = "outcome",
  clone_followup    = "fup"
)
clones_policy <- apply_logics(clones, policies)

censoring_logics <- create_censoring_logics_A(
  arms,
  treatment                 = "surgery",
  time_to_treatment         = "timetosurgery",
  grace_period              = grace_period,
  followup                  = "fup_obs",
  clone_censoring           = "censoring",
  clone_uncensored_followup = "fup_uncensored"
)
clones_censored <- apply_logics(clones_policy, censoring_logics)

setdiff(names(clones_censored$Surgery), names(lungcancer))
#> [1] "outcome"        "fup"            "censoring"      "fup_uncensored"

Each arm’s data frame now carries these four emulated variables alongside the original columns.

Expanding to person-time

Finally, create_final_data() expands each clone into a counting-process (“long”) table – one row per patient-time interval, bounded by Tstart and Tstop – the format the weighting step requires. Internally it finds every event time, splits each patient’s follow-up at those times, and combines the outcome and censoring information into one table per arm. Because each patient contributes several intervals, each arm has many more rows than the original 200 patients.

clones_final <- create_final_data(
  clones_censored,
  clone_followup  = "fup",
  clone_outcome   = "outcome",
  clone_censoring = "censoring",
  col_ids         = "id"
)
head(clones_final$Surgery)
#>      id surgery timetosurgery death sex charlson perf stage emergency fup_obs
#> 1 P5958       0            NA     0   2        1    2     2         1  365.24
#> 2 P5958       0            NA     0   2        1    2     2         1  365.24
#> 3 P5958       0            NA     0   2        1    2     2         1  365.24
#> 4 P5958       0            NA     0   2        1    2     2         1  365.24
#> 5 P5958       0            NA     0   2        1    2     2         1  365.24
#> 6 P5958       0            NA     0   2        1    2     2         1  365.24
#>       age deprivation fup_uncensored ID Tstart fup outcome censoring Tstop ID_t
#> 1 79.5729        0.42         182.62  1      0   1       0         0     1    0
#> 2 79.5729        0.42         182.62  1      1   7       0         0     7    1
#> 3 79.5729        0.42         182.62  1      7   8       0         0     8    2
#> 4 79.5729        0.42         182.62  1      8  10       0         0    10    3
#> 5 79.5729        0.42         182.62  1     10  16       0         0    16    4
#> 6 79.5729        0.42         182.62  1     16  18       0         0    18    5
sapply(clones_final, nrow)
#> Control Surgery
#>    8792   13980

Weight

The catch is that this artificial censoring is not random. Whether a clone deviates (and is censored) is related to its evolving health. If, say, sicker patients are more or less likely to have surgery, the censoring introduces selection bias, which inverse-probability-of-censoring weighting (IPCW) corrects [Robins and Finkelstein 2000].

Some notation first. Index individuals by $i$ and discrete follow-up times by $k = 1, 2, \dots$ ; let $L_0$ be the baseline covariates and $\bar L_k = (L_0, \dots, L_k)$ the covariate history through time $k$ . For a clone in a given arm, let $C_k = 1$ mean it is artificially censored at time $k$ , and $\bar C_{k-1} = 0$ that it was still uncensored up to time $k-1$ . The probability of being censored in an interval is modelled by pooled logistic regression on the person-time data – the discrete-time hazard approach of Efron [1988], whose close correspondence with time-dependent Cox regression is established by D’Agostino et al. [1990] –

$\operatorname{logit}\Pr\!\big(C_k = 1 \mid \bar C_{k-1}=0,\; \bar L_k,\; \text{arm}\big) \;=\; f(t_k) + \beta^\top L_k,$

with $t_k$ the interval start time. By default, $f(t_k)$ is linear. Setting time_spline_df = 3 uses a natural cubic spline with 3 degrees of freedom, allowing the baseline log-odds of censoring to vary nonlinearly over follow-up. Spline flexibility should be supported by enough censoring events; sparse or structurally concentrated censoring can otherwise cause separation. IPCW then multiplies each clone by the inverse probability of “remaining uncensored so far,” reallocating the contribution of censored clones to similar clones that remain. The unstabilized weight is

$W_i(k) \;=\; \frac{1}{\displaystyle\prod_{j=1}^{k} \Pr\!\big(C_j = 0 \,\mid\, \bar C_{j-1}=0,\; \bar L_j,\; \text{arm}\big)},$

and the stabilized weight replaces the constant numerator by a baseline-only model – the same regression, but with $L_0$ in place of $\bar L_j$ :

$SW_i(k) \;=\; \prod_{j=1}^{k} \frac{\Pr\!\big(C_j = 0 \,\mid\, \bar C_{j-1}=0,\; \bar L_0,\; \text{arm}\big)} {\Pr\!\big(C_j = 0 \,\mid\, \bar C_{j-1}=0,\; \bar L_j,\; \text{arm}\big)}.$

The denominator conditions on the full time-varying history $\bar L_j$ and models the actual censoring mechanism; the numerator conditions on baseline covariates $\bar L_0$ only, reducing the variance of the weights without changing the causal estimand; this stabilization is due to Robins, Hernán and Brumback [2000]. Taking the cumulative product across time gives $W_i(k)$ or $SW_i(k)$ .

In the package, estimate_censoring() fits these probabilities and adds the uncensoring probability P_uncens to each row; weight_cases() forms the weight in the column weight_Cox. Here age and sex are fixed at baseline and there are no time-varying covariates, so a stabilized weight with a baseline-only numerator would collapse to 1 at every interval and remove the adjustment entirely. We therefore use the unstabilized weight, whose denominator still adjusts for the age/sex dependence of censoring.

clones_estimated <- estimate_censoring(
  clones_final,
  predictors = c("age", "sex"),
  method = "pooled_logit"
)
clones_weighted <- weight_cases(clones_estimated)

It is good practice to inspect the weight distribution: extremely large weights inflate variance and can signal near-violations of positivity. Cole and Hernán [2008] give practical guidance on constructing and checking such weights.

weights_all <- unlist(
  lapply(clones_weighted, function(x) x[["weight_Cox"]]),
  use.names = FALSE
)
summary(weights_all)
#>    Min. 1st Qu.  Median    Mean 3rd Qu.    Max.
#>   1.000   1.054   1.176   1.409   1.532   4.751
hist(weights_all, breaks = 40, col = "grey80", border = "white",
     main = NULL, xlab = "IPC weight")

Distribution of IPC weights.

Estimating the effect

With clone-censor-weighted data in hand, emul_estimate() fits the weighted Cox model

$\lambda\!\big(t \mid \text{arm}, L\big) \;=\; \lambda_0(t)\,\exp\!\big\{\gamma\,\mathbb{1}(\text{arm}=\text{treated}) + \delta^\top L\big\},$

weighting each person-time record by its IPC weight. The per-protocol hazard ratio is $\mathrm{HR} = e^{\gamma}$ – the causal contrast specified in Section 2.

cox_fit <- emul_estimate(
  clones_weighted,
  method     = "Cox",
  weights    = "weight_Cox",
  predictors = c("age", "sex")
)
summary(cox_fit)$conf.int
#>             exp(coef) exp(-coef) lower .95 upper .95
#> armsSurgery 0.4905093   2.038697 0.3216575 0.7479989
#> age         0.9702208   1.030693 0.9150175 1.0287545
#> sex         0.4788167   2.088482 0.2543053 0.9015361

Because the weights make the effective sample differ from the raw data, the model-based standard error is unreliable. emul_estimate_bootstrap() resamples patients from the original subject-level data $B$ times. Within every resample, it repeats cloning, artificial censoring, person-time expansion, censoring-model estimation, weighting, and outcome-model estimation before taking the percentile interval [Efron and Tibshirani 1993] of the resulting hazard ratios,

$\big(\widehat{\mathrm{HR}}^{*}_{(\alpha/2)},\ \widehat{\mathrm{HR}}^{*}_{(1-\alpha/2)}\big),$

at confidence level $1-\alpha$ . The number of resamples $B$ is kept small here for speed.

boot <- emul_estimate_bootstrap(
  lungcancer,
  arms                   = arms,
  id                     = "id",
  treatment              = "surgery",
  time_to_treatment      = "timetosurgery",
  grace_period           = grace_period,
  outcome                = "death",
  followup               = "fup_obs",
  censoring_predictors   = c("age", "sex"),
  method                 = "Cox",
  predictors             = c("age", "sex"),
  n_bootstrap            = 10,
  seed                   = 1
)
c(
  HR = boot$estimate,
  HR_lower = boot$ci_lower,
  HR_upper = boot$ci_upper
)
#>        HR  HR_lower  HR_upper
#> 0.4905093 0.4050924 0.7313888

For a visual summary, method = "KM" returns weighted Kaplan-Meier curves for the two strategies.

km_fit <- emul_estimate(clones_weighted, method = "KM", weights = "weight_Cox")
plot(km_fit, col = c("#1b9e77", "#d95f02"), lwd = 2,
     xlab = "Days since time zero", ylab = "Survival probability")
legend("bottomleft", legend = arms, col = c("#1b9e77", "#d95f02"),
       lwd = 2, bty = "n")

Weighted survival curves by strategy.

Summary

Working through the surgery-in-lung-cancer question, this vignette:

motivated clone-censor-weighting with the problem of immortal time bias, and specified the target trial being emulated (Section 2);
cloned the subject-level data across a control and a surgery arm with clone_arms();
derived the grace-period policy and artificial-censoring rules with create_policy_A() and create_censoring_logics_A(), and evaluated them with apply_logics();
expanded the result into a person-time analysis dataset with create_final_data();
estimated censoring probabilities with estimate_censoring() and formed IPC weights with weight_cases(), inspecting their distribution;
and estimated the weighted per-protocol effect with emul_estimate(), with a percentile confidence interval from emul_estimate_bootstrap() and weighted Kaplan-Meier curves for a visual summary.

The same sequence applies to any dataset with the five columns listed in Section 2: an identifier, a binary treatment, a time to treatment, a binary outcome, and a follow-up time.

References

Cole, S. R., & Hernán, M. A. (2008). Constructing inverse probability weights for marginal structural models. American Journal of Epidemiology, 168(6), 656-664.

D’Agostino, R. B., Lee, M.-L., Belanger, A. J., Cupples, L. A., Anderson, K., & Kannel, W. B. (1990). Relation of pooled logistic regression to time dependent Cox regression analysis: the Framingham Heart Study. Statistics in Medicine, 9(12), 1501-1515.

Efron, B. (1988). Logistic regression, survival analysis, and the Kaplan-Meier curve. Journal of the American Statistical Association, 83(402), 414-425.

Efron, B., & Tibshirani, R. J. (1993). An Introduction to the Bootstrap. Chapman & Hall, New York.

Gaber, C. E., Ghazarian, A. A., Strassle, P. D., Ribeiro, T. B., Salas, M., & Maringe, C. (2024). De-mystifying the clone-censor-weight method for causal research using observational data: a primer for cancer researchers. Cancer Medicine, 13(23), e70461.

Hernán, M. A. (2018). How to estimate the effect of treatment duration on survival outcomes using observational data. BMJ, 360, k182.

Hernán, M. A., Brumback, B., & Robins, J. M. (2000). Marginal structural models to estimate the causal effect of zidovudine on the survival of HIV-positive men. Epidemiology, 11(5), 561-570.

Hernán, M. A., & Robins, J. M. (2016). Using big data to emulate a target trial when a randomized trial is not available. American Journal of Epidemiology, 183(8), 758-764.

Hernán, M. A., Wang, W., & Leaf, D. E. (2022). Target trial emulation: a framework for causal inference from observational data. JAMA, 328(24), 2446-2447.

Maringe, C., Benitez Majano, S., Exarchakou, A., et al. (2020). Reflection on modern methods: trial emulation in the presence of immortal-time bias. International Journal of Epidemiology, 49(5), 1719-1729.

Robins, J. M., & Finkelstein, D. M. (2000). Correcting for noncompliance and dependent censoring in an AIDS clinical trial with inverse probability of censoring weighted (IPCW) log-rank tests. Biometrics, 56(3), 779-788.

Robins, J. M., Hernán, M. A., & Brumback, B. (2000). Marginal structural models and causal inference in epidemiology. Epidemiology, 11(5), 550-560.

Jihyeon Baek, Hye Won Yang

2026-08-12
